X-ray drawings of Messerschmitt aircraft 11 pages After the war, the Messerschmitt-Boelkow-Blohm company published this series of drawings of the most famous Messerschmitt designs. Except for the spanish Ha 200 jet trainer the drawings are from the war period. Free download as PDF (The file may not be modified - commercial use is prohibited.)
Messerschmitt Me 262 with additional Lorin Ramjet engines 1 page Developed by rocket pionier Eugen Saenger, this ramjet engines were testflown on a Dornier Do 217 and proposed for several fighter projects. Messerschmitt company drawing. Free download as PDF (The file may not be modified - commercial use is prohibited.)
Dornier Do 217 N-1 Luftwaffe Nightfighter 1 page Dornier Factory Drawing Free download as PDF (The file may not be modified - commercial use is prohibited.)
Dornier Do 217 J-1 Luftwaffe Nightfighter 1 page Dornier Factory Drawing Free download as PDF (The file may not be modified - commercial use is prohibited.)
Messerschmitt Bf 109 G-14 1 page Luftwaffe fighter Messerschmitt Bf 109 G-14 with larger tail and rudder. This is “blue 11”, serial number 460520 of  12. Staffel from Jagdgeschwader JG 76 photographed in September 1944. Free download as JPG (The file may not be modified - commercial use is prohibited.)
Cockpit section of Junkers Ju 88 A and Ju 88 B 1 page Junkers proposed a new version of its Ju 88 bomber with redesigned cockpit section. This was later produced as Ju 188. Junkers company drawing. Free download as PDF (The file may not be modified - commercial use is prohibited.)
Weapons of Heinkel He 111 H-5 1 page Internal arrangement of bomb bay and defensive weapons. Language: German Free download as PDF (The file may not be modified - commercial use is prohibited.)
Heinkel He 111 H-5 with heavy bomb load of 2 x 1000-kg-bombs 1 page Language: German Free download as PDF (The file may not be modified - commercial use is prohibited.)
Heinkel He 111 H-5 with heavy bomb load of 4 x 250-kg-bombs plus 1 x 1000-kg-bomb 1 page Language: German Free download as PDF (The file may not be modified - commercial use is prohibited.)
Dornier Do 17 E-1 Code TI+BL of Luftwaffe Flight School FFS C6 The aircraft seems to be undergoing an engine repair - not an easy task in these harsh winter conditions! 1 page Free download as JPG (The file may not be modified - commercial use is prohibited.)
Junkers Ju 288 G with large canon Project to fit a Ju 288 bomber with a large canon as a anti- shipping weapon. The gun with the caliber of 355 mm (!) should be recoilless. The aircraft should perform a vertical dive and turn above the range of light and medium naval flak. Language: German 1 page Free download as PDF (The file may not be modified - commercial use is prohibited.)
Technical details of East-German jet airliner Baade 152 In the late 1950s, German engineers (mostly from Junkers) returning from the USSR developed a jet airliner in East Germany. The Baade 152 was to be sold worldwide. After the crash of the first prototype, the aircraft had to be modified. When the Soviet Union became the only country allowed to build commercial aircraft in the East, the project had to be terminated. Language: German 8 pages Free download as PDF (The file may not be modified - commercial use is prohibited.)
Advertising brochure for the Noratlas transport aircraft France developed its own transport aircraft after World War II. the Noratlas made its first flight on September 10, 1949. In the late 1950s, the Noratlas was also built under license in Germany. This advertising brochure, which also presents a civilian version of the Noratlas as an airliner, dates from this period. Language: German 24 pages Free download as PDF (The file may not be modified - commercial use is prohibited.)
